AVENGER 26 HP VST Agro
The new generation AVENGER Tractor naturally aspirated and Powerful Engines are synonymous with High Performance, Reduced Fuel Consumption.
View BrochureHome / Tractors / AVENGER 26 HP VST Agro
The new generation AVENGER Tractor naturally aspirated and Powerful Engines are synonymous with High Performance, Reduced Fuel Consumption.
View BrochureAvenger 26 is capable of exciting performances. 26-HP model meets the Euro III Emission Standards. Daily maintenance and Service Checks are facilitated by the new frontal opening hood.
The hydraulic system uses an open-centre ADDC system with a gear-type pump.
Show More
The constant-mesh gearbox provides three speed ranges—High, Medium and Low—with nine forward speeds and three reverse speeds.
Show More
The 4WD system provides traction across different soil and terrain conditions. This makes the AVENGER 26 suitable for agricultural work where compact dimensions and traction are both important.
Show More
The AVENGER 26 VST Agro uses a compact VST diesel engine designed to provide practical power for small-scale farming and utility operation.
Show More| Engine Specifications | ENGINE Model / Make MVL3E / MHI | HP Category: 26 | Type: 4 Cycle, Vertical Overhead Valve, Cylinder in Line, Swirl Chamber Type | No. of Cylinders: 3 Cylinders | Bore / Stroke (mm): 78 / 92 | Rated Engine (RPM): 2500 | Displacement (CC): 1319 | Fuel Pump: In-Line Type | (ND-PFR M Type) | Air Cleaner Type: Dry with Clogging Sensor | |
| Clutch | Type: Heavy Duty Dry Type Single | Plate Size: Dia 224 mm | |||||||||
| Transmission | Gear Box: 9F + 3R Constant Mesh | ||||||||||
| Road Speed Km/Hr | FORWARD (High, Medium and Low) | – Gear 1: 9.19 – 4.64 – 1.46 | – Gear 2: 12.98 – 6.55 – 2.06 | – Gear 3: 21.35 – 10.78 – 3.39 | REVERSE Gear: 10.63 – 5.36 – 1.69 | ||||||
| Hydraulic System | Type: Open Center, ADDC | Hydraulic Pump: Gear Type | Linkage: TPL Category-N | Lifting Capacity (Kg.): 750 | |||||||
| Steering | Type: Power Steering | ||||||||||
| Power Take Off | Type: 2 Speed | Splines: 6 | P.T.O Speed: 540 @ 2500, 540 E @ 2035 | ||||||||
| Capacities (Litres) | Fuel Tank: 25 | Engine Sump: 3.7 | Cooling System: 5.8 | Transmission & Hydraulic: 18±10% | |||||||
| Electrical Installation | Battery: 12V, 65 Ah | Alternator: 12V, 65A | Starter Motor: 12V, 1.7 KW | ||||||||
| Minimum Turning Radius | Without Breaks (m): 2,6 | ||||||||||
| Tyre Size 4WD | Front: 6.00 – 12 | Rear: 8.3 – 20 | Weight (Kg.): 1130Cell | ||||||||
| Front Drive Axle for 4WD Only | Differential | Total Ratio: 1:13.81 | Oil Capacity (Ltr.): 3.2 Ltr. | ||||||||
| Brakes | Type: Multi Disc, Oil Immersed | ||||||||||
| Dimensions | Overall Length: 2860 mm | Width: 1120 mm | Height: 2570 mm | Ground Clearance: 293 mm | Wheel Base: 1542 mm | Front Track: 860 mm | Rear Track: 820 mm |
